The Voltera V-One is a circuit board printed and solder reflow for working with surface mount components. In the Maker Lab we have a Voltera V-One.


Quick Reference

Training Required: Basic Training and Voltera Training

Workspace: 135 x 113.5 mm (5.3x4.4 inches)

Materials: FR-4 blanks

File Types: Gerber

Material Fees: 2"x3" and 3"x4" boards are sold in the Maker Store

Common Terminology: Solder Paste- Powdered metal solder and flux mixed together to create a temporary adhesive; Reflow soldering- Process in which a solder paste is used to temporarily attach components and then heat is applied to create permanent joints.


PDF Links

Voltera Manual


Video Links

Maker Lab Blinking LED Project

Voltera YouTube Channel


Software

Software for creating gerber file:

Eagle (Autodesk)

KiCad

Software for sending gerber file to the Voltera V-One:

Voltera Desktop Software


Manufacture Information

Voltera Website

Voltera Guides


Sample Projects

Blinking LEDs

Printed circuit with LEDs and 555 timers to make the LEDs blink.
